Equipment Overview
Portable spot welding machine SW-80N — review the equipment details and specifications below. Contact BLUESKY to discuss a configuration for your workshop.
Description
Description
Brife: 230V or 400V steel dent puller with 3800A output current, ideal for all steel
straightening and dent pulling jobs. Simple to use thanks to its automatic gun and its user
friendly control panel.
Only 2 parameters to select
* the output power level (11 levels)
* the tool which is used (7 tools, triangle/rings/wave wire/pressing/spot welding/shrinking/rivets)
* no need to select the welding current and welding time anymore.
straightening and dent pulling jobs. Simple to use thanks to its automatic gun and its user
friendly control panel.
Only 2 parameters to select
* the output power level (11 levels)
* the tool which is used (7 tools, triangle/rings/wave wire/pressing/spot welding/shrinking/rivets)
* no need to select the welding current and welding time anymore.
Automatic triggering
The welding is triggered automatically by a simple contact between the tool and the part to straighten.
| Name | Steel Dent Pulling Machine |
| Rated Power | 2.2 KVA |
| Output current | 3800A |
| Output voltage | 6-8V |
| Welding mode | Induction welding |
| Number of welding guns | Single gun |
| Packing size | 57*46*62cm |
| Weight | 45kg |
| Voltage | 220v/380v, 50/60hz |
Request a Quote
Send the model, quantity, destination country and available electrical supply to sales@lantian-huaer.com. Configuration, delivery and documentation requirements will be reviewed with your quotation.
